You should test a mounting location before you permanently mount the camera.When selecting a location to mount the camera, observe these considerations. If your GPS device includes lifetime traffic, the traffic features continue to function while using the BC 30 receiver cable. NOTE: The BC 30 receiver cable includes a traffic receiver.

#GARMIN BACKUP CAMERA WIRING DIAGRAM BC30 MANUAL#

See the owner's manual for your GPS device for more information about connecting the device to vehicle power. Use the BC 30 receiver cable included with your BC 30 camera to connect your GPS device to vehicle power. The wireless camera receiver is built into BC 30 receiver cable included with your wireless backup camera. See your GPS device owner's manual or go to /express for more information about updating your GPS device. Your GPS device may not be compatible with the BC 30 camera

#GARMIN BACKUP CAMERA WIRING DIAGRAM BC30 INSTALL#

RV sealant (optional) Installation Installing the Receiverīefore you can install the BC 30 receiver cable, you must update your GPS device to the most recent software version.

Solderless wire-splice connector or solder and heat-shrink tubing.

Screws, bolts, or cable ties (to secure the transmitter).

Drill and 9.09 mm, or size T (0.36 in.) drill bit.

The GPS device must be powered through this cable to For questions specific to your vehicle, you should contact the vehicle manufacturer. These installation instructions do not apply to a specific vehicle type, and are meant as a guide when installing this product on your vehicle. When drilling or cutting, always check what is on the opposite side of the surface. In addition, connecting the power cable without the appropriate fuse in place will void the product warranty.Īlways wear safety goggles, ear protection, and a dust mask when drilling, cutting, or sanding. To prevent the possibility of injury or product damage caused by fire or overheating, the appropriate fuse must be in place as indicated in the product specifications. When connecting the power cable, do not remove the in-line fuse holder. Incorrectly wiring the power cable can result in damage to the vehicle or the battery and can cause bodily injury. Garmin ® strongly recommends having an experienced installer with the proper knowledge of electrical systems install the device. See the Important Safety and Product Information guide in the product box for product warnings and other important information. These trademarks may not be used without the express permission of Garmin. or its subsidiaries, registered in the USA and other countries. Garmin ® and the Garmin logo are trademarks of Garmin Ltd.
